Frequency Range:(220-260MHz)

* Output Power: 10W/25W/45W/60W

* 1750Hz Tone

* CTCSS/DCS setting & scanning

* 0-9 SQL grade setting

* Frequency/Channel scanning

* High/Mid/Low power selectable

* Voice compander

* Repeater offset shift

* Keypad lock function

* Contact book

* Battery voltage display

* DTMF/2 tone/5 tone

* ANI ID

* Remote kill/ stun/ activate/ revive

* Emergenvy alarm

* Wide/Narrow band setting

* TX inhibit

* Busy Channel Lock-Out

* Channel name editing

* Reverse frequency

* Talk around

* Scrambler(Optional)

* Voice prompt

* Time-out Timer

* Auto Power off

* VFO step setting:5/6.25/10/12.5/20/25/50kHz

Item Number

TH-9000D

General

Frequenvy Range

(220-260MHz)

Channel Capacity

200

Channel Spacing

5/6.25/8.33/10/12.5/15/20/25/30/50KHz

Freruency Stability

2.5ppm

Operating Temperature

-20C ~ + 60C

Operating Voltage

13.8V DC 15%

Dimension(HxWxD)

145mm x190mm x47mm

Weight(with bracket)

1200g

Receiver

Reference Sensitivity

0.25V / 0.35V

Operating Bandwidth

60dB#12.5KHz /70dB#25KHz

Adjacent Channel Selectivity

60dB#12.5KHz 70dB#25KHz

Inter-modulation Rejection

60dB/ 65dB

Spurious Response Rejection

70dB

Rated Audio Response

+1-+3dB

Rated Audio Distortion

<5%

FM Hum&Noise

40dB#25KHz /45KHz #12.5KHz

Transmitter

RF Power

60W/45W/25W/10W

Frequency Modulation

11kF3E / 16kF3E

Modulation Distortion

<5%

FM Noise

36dB#25KHz /40KHz #12.5KHz

Adjacent Channel Power

60dB#12.5KHz /70KHz #25KHz

Audio Response

+1-+3dB

Audio Distortion

<5%
